POX Web Interfaces

September 12, 2012 in POX

NOX-Classic has had a Qt based GUI for quite a while now, and in slightly modified form, it made it into POX as well.  However, I do hear requests for a web-based GUI from time to time.  I’d like to briefly discuss three relevant items: my own extensible web-based GUI for POX (POXDesk), POX-based JSON-RPC webservices, and Sam Russell’s work using POX with Django.  And if you’re not that interested in the technology behind it, I’ll post some pretty pictures too.

Sam Russell’s Django POX UI

Django and POX

I’ll actually go in reverse order here, so I’ll start by mentioning that POX user Sam Russell (who has been posting on his blog about POX) has written a couple nice posts about integrating POX with Django to get a POX web interface.  This works out pretty well, since POX and Django are both Python frameworks and just sort of snap together.

His blog posts are actually pretty much a crash course on getting started with Django for POX/OpenFlow developers, and if this is the sort of thing you’re interested in, you should absolutely give it a read.

POX Webservices

The development branch of POX (which will soon be getting put in the main repository) has better support for the web built in.  [Update: This has now happened: it's the betta branch of the POX repository.] This comes in two forms.

JSON-RPC over HTTP

The first is that there’s some infrastructure in POX now to ease the implementation of JSON-RPC-over-HTTP webservices.  This will hopefully make it fairly straightforward to expose your applications’ capabilities to web clients.

POX also includes a sample webservice built using this: the OpenFlow webservice.  This currently allows a number of operations, such as querying this list of switches, getting some switch statistics, and both querying and setting flow tables.  The last one means that if you really want to, you can construct OpenFlow table entries in JSON and push them to a switch from the web.  For example, you can turn a switch into a hub by issuing the following HTTP POST:

{
 "method":"set_table",
 "params":{
           "dpid":"00-00-00-00-00-01",
           "flows":[{
                     "actions":[{"type":"OFPAT_OUTPUT","port":"OFPP_ALL"}],
                     "match":{}
           }]
  }
 }

The “flows” mentioned above are a fairly straightforward translation of the OpenFlow spec into JSON.  The rule above matches all traffic (unspecified fields are wildcards) and outputs matching packets to all ports — Presto.

Improved Web Messenger

POX’s messenger system is a mechanism to help ease the burden of communication between POX and external systems (including POX-to-other-POX communication).  The system is transport agnostic, and has had an HTTP-based transport for a while (used by POX-at-Home, for example).  Messenger has gotten a substantial makeover recently, though, and the web messenger has gotten some fixes and improvements along with it.  While the web_transport uses an ad hoc communication, we’ve also introduced a new ajax_transport.  While the name is silly, this latter one is really just long-polling JSON-RPC over HTTP interfacing with a few methods to let you interact with the messenger.

Along with the actual transport improvements, there have also been improvements and additions to services implemented atop the messenger, and you can now use those over web_transport or ajax_transport (or the straight socket tcp_transport, course).  One such addition is an OpenFlow service similar to the special-purpose OpenFlow webservice mentioned above.  Unlike that one, though, the messenger service supports notifications (I’ll come back to that in a moment).

POXDesk

The POX Menu opened to show current POXDesk applications

Utilizing the new OpenFlow messenger service, the new messenger’s features in general, the Qooxdoo JavaScript famework, and some repurposed code I wrote a couple of years ago, I’ve also started hacking up my own web-based POX GUI.  This also contains the start of a decent JavaScript “client side” implementation of the AJAX messenger.  POXDesk is written in a modular and multi-modal way, which I hope will make it easy for people to add on features specific to their own needs and POX-side applications.

I’ve also got a few applications to start out with.  These include some of the obvious things, such as a POX log viewer (using the log messenger service), an OpenFlow table inspector (using the new OpenFlow messenger service), and a simple force-directed topology viewer (using openflow.discovery).  There are also a couple of non-obvious ones.  As I said, the OpenFlow messenger service actually supports notifications — and this includes packet-ins.  So POXDesk also includes a reactive L2 learning switch implemented in JavaScript; it’s kind of nice, because it has a little display that shows the entries it has learned.  Secondly, POXDesk has a JavaScript terminal emulator (a heavily modified version of the one by Frank Bi).  I think there are a number of potential uses for this.  At the moment, it just gives you a bash shell, which this actually is kind of nice if you are, for example, running the Mininet VM on Windows: no need for PuTTY and a Windows X server — just a web browser.

Here’s some additional screenshots for you:

L2 Learning Switches

TopoViewer (tree)

Terminal (Mininet)

POXDesk is still really rough around the edges, and I haven’t released the code yet, but I think it’s coming along.  [Update: It's still really rough around the edges, but the code is now public on my github account if you want it!] Likewise, it’s still early days for the new messenger stuff in POX, though that should be getting moved to the mainline quite soon. [Update: This has happened in the betta branch.]

At any rate, I hope those of you interested in doing web based GUIs with POX have found this informative, and maybe even found something you’d like to use as a base for your own work.  And please let me know if I’ve missed anything that should be mentioned here!
